Forklift Pinion - The king pin, normally made of metal, is the main pivot in the steering device of a vehicle. The original design was in fact a steel pin wherein the movable steerable wheel was attached to the suspension. Able to freely rotate on a single axis, it limited the levels of freedom of movement of the rest of the front suspension. During the 1950s, the time its bearings were substituted by ball joints, more comprehensive suspension designs became accessible to designers. King pin suspensions are still used on some heavy trucks as they have the advantage of being capable of carrying a lot heavier load.
New designs no longer limit this particular device to moving similar to a pin and these days, the term might not be used for an actual pin but for the axis in the vicinity of which the steered wheels pivot.
The kingpin inclination or otherwise called KPI is likewise called the steering axis inclination or SAI. This is the explanation of having the kingpin set at an angle relative to the true vertical line on most recent designs, as viewed from the front or back of the forklift. This has a vital effect on the steering, making it tend to return to the centre or straight ahead position. The centre location is where the wheel is at its uppermost position relative to the suspended body of the forklift. The motor vehicles weight tends to turn the king pin to this position.
One more impact of the kingpin inclination is to arrange the scrub radius of the steered wheel. The scrub radius is the offset between the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these items coincide, the scrub radius is defined as zero. Even if a zero scrub radius is possible without an inclined king pin, it needs a deeply dished wheel in order to maintain that the king pin is at the centerline of the wheel. It is more sensible to tilt the king pin and make use of a less dished wheel. This also offers the self-centering effect.
